I. Vehicle Parameters

Brand: Mercedes-Benz.

2. Color: White, red, blue.

3. Engine model: 274920.

4. Displacement: 1991(ml).

5. Rated power: 155/210 kW /rpm.

6. Wheelbase: 3430(mm).

7. Type of fuel: Gasoline.

8. Emission Standard: National VI.

9. Overall and internal dimensions of the vehicle: 5370mm×1928mm×2370mm.

10. The length of the medical cabin: 2560mm×1560mm×1750mm.

11. Track (front and rear) : 1666/1646mm.

12. Number of passengers (including the driver's cabin) : 7(including stretchers).

13. Maximum speed: 185km/h.

14. Total mass: 3100kg.

15. Curb weight: 2400kg.

16. Suspension System: Agile control suspension system.

17. Braking system: Dual-circuit hydraulic brake, four-wheel disc type.

18. Transmission: 9-speed automatic transmission.

19. Fuel tank capacity :70 liters.

Ii. Standard Vehicle Configuration

Anti-lock braking system (ABS).

2. Electronically controlled vehicle stable Driving system (ESPO 9i).

3. ATTENTION ASSIST System.

4. SIDE WIND ASSIST Control Assist System.

5. Hill start assist.

6. ECO engine start and stop functions.

7. Cruise control.

8. Tire pressure monitoring system.

9. The driving authorization system includes engine anti-theft features.

10. Tire pressure monitoring system.

11. Electric mechanical power steering.

12. Two seats in the cab.

13. Driver and co-pilot airbags.

14. Electric window, central door lock with remote control function, electric window side rearview mirror, front and rear fog lights.

15. Install a large-screen navigation all-in-one machine in the cab.

16. Rear hatchback door.

Iii. Air Conditioning and Lighting Systems

The cab is equipped with an original factory air conditioning system

2. Air conditioning and heating systems after the negative pressure chamber becomes independent

3. The negative pressure cabin is made of an integrated vacuum-formed material with a bidirectional air intake and exhaust system installed on the inner top. The upper exhaust ventilation design can meet the ventilation needs inside the cabin.

4. The negative pressure chamber is made of an integrated vacuum-formed material with a ring-shaped LED lighting lamp installed on the inner top. It adopts backlight technology, features an ultra-thin structure, and provides uniform light emission, soft and comfortable light that does not irritate patients while ensuring moderate illumination, meeting the actual operational needs of medical staff.

5. The negative pressure chamber is made of an integrated vacuum-formed material with infusion spotlights installed on the inner top.

6. The negative pressure chamber is made of overall vacuum-formed material and equipped with ultraviolet disinfection lamps.

7. The 360-degree spotlights are installed at the rear of the negative pressure chamber.

Iv. Central Power Supply System

The negative pressure chamber is equipped with an intelligent 1500W sine wave inverter power converter with charging function, featuring stable frequency, voltage and output power.

2. The negative pressure chamber is equipped with a backup battery pack.

3. 220V/10A waterproof, aviation type external power socket with protective cover, equipped with 10m long external mobile cable.

4. Five 220v sockets and one 12V socket are installed in the negative pressure chamber.

5. The negative pressure cabin is equipped with an integrated intelligent electrical control system, which can achieve dual control of the medical cabin and the driver's cabin.

V. Emergency Alarm System

Alarm and warning light controllers are installed in the cab.

2. The alarm is designed in a split style. The control handle integrates an independent rescue sound button and a night volume mode.

3. Special blue LED embedded police lights for Mercedes-Benz are installed at the front of the roof and the rear of the vehicle.

4. White LED outdoor lighting fixtures are installed on both sides of the rear of the vehicle body.

5. A blue LED strobe light is installed at the front grille of the front of the vehicle.

Vi. Devices inside the negative pressure chamber

1. The overall environmentally friendly lightweight vacuum-formed material middle partition wall assembly of the negative pressure chamber is equipped with a fixed window. A folding doctor's seat with armrests and safety belts is installed at the middle partition wall.

2. Two 10-liter oxygen cylinders are placed in the oxygen cabinet of the negative pressure chamber, with a nominal pressure of 10MPA. The connection between the oxygen pressure reducing valve and the pipeline adopts a metal quick union to ensure safety and convenience. The vehicle is equipped with a humidification bottle, which can be disinfected at high temperature to ensure safety and durability.

3. Oxygen terminal (German style) quick plug-in type.

4. Ventilator connector (German style) Quick plug-in type.

5. An oxygen balance monitoring system is installed above the oxygen cabinet in the negative pressure chamber.

6. The inner top of the negative pressure chamber is made of environmentally friendly lightweight ABS vacuum-formed composite panels, and a one-time mold forming process is selected. The back is reinforced and strengthened with a lightweight aluminum alloy frame as structural components, featuring light weight, rust resistance, and high structural strength. The functional accessories on the inner top adopt an embedded positioning design According to the actual operation requirements, it integrates functions such as medical cabin lighting, storage, exhaust, air purification, sterilization, infusion, and all-round handrails.

7. The interior of the environmentally friendly lightweight medical ABS vacuum forming mold, integrated multi-functional inner top core, top, left side, right side, middle partition, medical cabinet, wall cabinet, cabinet seat, etc. are all made of ABS vacuum forming composite material through one-time mold forming process. The material has the advantages of high hardness, smoothness, antibacterial, easy cleaning, disinfection and anti-aging. And it meets the requirements of lightweight, safety and environmental protection.

8. On the left side of the negative pressure chamber, there is an integral formed vacuum-formed material medical cabinet with a wall cabinet, which can separately place large items such as disposable medicines, external injury bandaging supplies, isolation protection, etc. (half a cabinet can be optionally installed).

9. A doctor's seat is installed on the right front side of the negative pressure cabin, and a two-person cabinet-style seat is installed at the rear, equipped with a safety belt.
