I. Vehicle Parameters

Overall dimensions: 10190×2550×3730(mm)

Total mass: 33,700 (Kg)

Curb weight: 15,250 (Kg)

Rated load capacity: 18,000 (Kg)

Cab: Front passengers: 2+4(people)

Anti-lock braking system: Yes

Approach Angle/departure Angle: 19/11(°)

Front overhang/rear overhang: 1500/2690(mm

Shaft load: 8700/12500/12500

Wheelbase: 4300+1400,4325+1350,4600+1400,4625+1350,5200+1400,5225+1350,5800+1400,5825+1350(mm)

Number of axes: 3

Maximum speed: 100 km/h

Number of spring pieces: 10/12,4/12,4/5,4/-/-

Number of tires: 10

Tire size: 385/65 r22. 5/315/80 r22. 18 pr 5, r22 385/65. 5/12.00 R20 18 pr

Front track: 2110(mm)

Rear track: 1830/1830,1850/1850(mm)

Chassis model: ZZ5357TXFV464MF5

Ii. Vehicle Characteristics

1. Large foam system capacity: The most notable feature of the 18-cubic-meter foam fire engine is its large foam system capacity, which can store a large amount of foam liquid for extinguishing large-scale fire sources.

2. High-pressure foam fire extinguishing system: This type of fire engine is usually equipped with a high-pressure foam fire extinguishing system, which can spray foam liquid onto the fire source at a relatively high pressure to quickly extinguish the flames.

3. Multi-functional foam gun: Equipped with a multi-functional foam gun, it can adjust the spray Angle and range of the foam to adapt to different fire extinguishing scenarios and improve the accuracy of operation.

4. Diverse types of foam liquids: The 18-cubic-meter foam fire engine can carry various types of foam liquids, including flame-retardant foam and explosion-proof foam, to deal with different types of fires, such as oil and chemicals.

5. Automatic foam fire extinguishing system: Some 18-cubic-meter foam fire engines are also equipped with an automatic foam fire extinguishing system, which can automatically adjust the amount of foam sprayed according to the size of the fire source and the changes in the fire situation, thereby improving the efficiency of fire extinguishing.

6. High-efficiency cooling effect: The foam fire protection system forms a foam film on the surface of the fire source, which has a good cooling effect, effectively reducing the temperature of the fire source and preventing the spread of fire.

7. Chemical Suppression: The 18-cubic-meter foam fire truck can be used to extinguish and suppress chemical fires. Through the physical and chemical properties of the foam, it prevents the fire source from coming into contact with oxygen in the air, achieving the purpose of controlling the fire.

8. Fully automatic hydraulic operating system: Some modern foam fire engines are equipped with fully automatic hydraulic operating systems, which enhance the vehicle's handling and response speed.

Large-capacity water tank: To ensure there is sufficient water source during long-term fire-fighting operations, 18-cubic-meter foam fire engines are usually also equipped with large-capacity water tanks.
